Quick Details

  • Type: Other
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: YIHUA
  • Model Number: 853AAA
  • Voltage: 110V/220V/230V/240V OPTIONAL
  • Current: 6A
  • Dimensions: 37*38*18cm
  • Weight: 5.54KGS/PCS
  • Usage: It is suitable for repairing electronic equipment, mobile phone, ect.
  • Certification: CE ISO
  • After-sales Service Provided: No overseas service provided
  • Outer carton box size: 73*40*39cm
  • Q'ty: 4pcs /outer carton
  • G.W.: 23.41KG/CTN

Packaging & Delivery

Packaging Details 4 pcs per outer box carton
Delivery Time within 7 working days when we got the payment



YIHUA 853AAA bga rework station


Product Description



Feature



1.Using microcomputer processor PID programmable temperature control technology.

2.Preheating station is to use a glaze layer having a high thermal effect, good thermal shock resistance of the ceramic as the substrate, high-quality nickel branded alloy wire once sintering.

It has a high thermal effect, overall good, good thermal stability, uniform heating, high dielectric strength, clean, easy to install and so on features.

3.Air Gun heater use ceramic heater.

heating elements firmly wrapped around the model ceramic, rapid and uniform heating.

Use the upgraded version fan, the airflow larger than the ordinary fan, spiral out of the wind, long life.

4.Soldering iron part using Imported heater.

heating up rapidly, temperature stability, long service life; antistatic design to prevent electrostatic damag to delicate   SMD components.

5.The machine has a self-test function.

full intelligent over-temperature, short-circuit, open circuit, overload and fault display and protection functions.

6.853AAA preheating station using the user-friendly design.

the cover affixed with a high-temperature, insulated protection pads to prevent scalding operation.

Uses magnetic induction technology.

Card board bracket to prevent protective pads suck hood above.

Can rotate 360 degrees, flexible card board.

It is suitable for the circuit boards of different shapes and sizes.

7.853AAA temperature correction function

Adapt to the environmental impact, or replace the heating elements, soldering iron tips etc. spare parts caused by temperature deviation,can use this function calibration temperature.

The correction temperaturerange is -50 °C ~ +50 °C.

8.853AAA has Celsius / Fahrenheit temperature display function

Meet different market needs to design the temperature display mode, you can choose under customary interest.



YIHUA 853AAA bga rework station Data



Voltage AC220C±5%

Max power consumption 1270W





Preheating station parts



Temperature Range 50~400  °c / 152~752 °F

Temperature Stability ±2  °c

Display Type LED

Area 120*120mm



Hot Air Reworks parts



Airflow type brushless fan spiral out wind

Air Flow ≤130L/min

Temperature Range 100  °c -480  °c /212°F ~896 °F

Temperature Stability  ±1  °c

Display Type LED

Handle cable length ≥100cm



Soldering Iron parts



Temperature Range 200 °c -480 °c /392°F~896 °F

Soldering iron heater Hakko heater

Solder iron holder blue Ferro-alloy iron holder

Soldering iron handle Blue iron handle

Temperature Stability ±1°c

Tip of ground voltage <2mV

Tip ground impedance <2 ohm

Display Type LED

Handle cable length ≥100cm





  NOTE:Due to shippment cann't contain rosin,so the tip cleanner box don't have rosin inside.



 General Usage



1). Suitable for de-soldering and soldering BGA, SOIC, CHIP, QFP, PLCC package SMD IC,

 Particularly suitable for de-soldering BGA module, computer motherboard north and south bridge, all kinds of mobile phone motherboard SMT IC and LED lights.

2). Shrinking, Paint drying, adhesive removal, thawing, warming, Plastic welding etc.





YIHUA 853AAA bga rework station  package:



Inner box size  37*38*18cm

Outer carton box size  73*40*39cm

Q'TY  4pcs/ctn

Goods net weight  5.54kg/pcs

outer carton weight  23.41kg





These are 220V units you may need a transformer to use the machine in your country. we also do accept special orders for 110V  / 230V/ 240V units





Company Information Display



Guangzhou YIHUA Electronic Equipment CO., Ltd was founded in the 1980s, which transferred from

a large scale army enterprise called 083 base. It has become the biggest and most powerful

manufacturer for making professional rework station and soldering station and DC power supply and

our sales all over the world.

Certification of our products



We have passed the ISO9001-2008 international quality management system and our products have

passed the European CE certification, the United States,ETL certification, SAA certification, SGS

certification, the depth of export certification and Korea KC certification and so on.

Chinese Soldering Industry Standard Maker



2016,our company was invited to attend Standard Committee for Household Electrical Appliances--Chinese Soldering Industry Standard Set.

Complete Quality Test System



All of our products are passed testing by professional person before shipping, let you don't need to worry about the quality.

Our warranty

*Credit Safeguard

GuangZhou YiHua Electronic Equipments Co,. Ltd  was signed a contract with Alibaba and  paid a large deposit, make buyers fee l comfortable buying

*Factory advantage

Factory D&R / production/ sales/ and sales service together.

Manufactory  sell directly,the goods are in plenty supply,delivery date fast,good compete price You could arrange to ship the goods by your self , or  ask we help you arrange to ship. If  we help you arrange to ship. Before quote the shipping freight, we need to know which model and quantity you are asking. We will according your detail address, order model and quantity to advise  you ship by sea  or, by air ,or by Express. As usual, we are using HongKong DHL to ship the small order..

*Delivery date

Over 100~over500pcs are 20days  will ship out. Over 1000pcs are 30days .

If the material not enough or we have some customer  queue up our products before you,

we will discuss with you the shipping date. If you want the delivery date faster than that day, please inquiry us, we will try to do it as your request.

*Warranty policy

One Years warranty

As usual, the shipping fee are high. if return China to repair are not worth the money. So we could support technology and give you the spare parts along with the product .

Note: warranty does not cover wearing parts:, for example :iron heater, gun heater ,iron tips.

*Products  discount

as usual we quote three price for each model :sample price, over 60pcs price, over 500pcs price.

Those price are calculate our produce cost, as you know big order are less margin to sell. we hope take win-win business with both.

*Warm-heart  note

1.If products upgrade or quality improve to change the technique parameter, the factory will not further notice.

2.If the customer haven't special request, the product in accordance with factory's setting quality standards to produce.
