Quick Details

  • Type: Other
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: YIHUA
  • Model Number: 992DA+
  • Voltage: 110V/220V/230V/240V optional
  • Current: 6A
  • Dimensions: 33*27*20.2cm
  • Weight: unit net weight :5.13KG/PCS
  • Usage: soldeing ,de soldering and smoke absorber
  • Certification: CE
  • After-sales Service Provided: No overseas service provided
  • Digital type: large-screen LCD display
  • airflow display type: Dynamic wind speed display
  • Gun type: diaphragm pump ,air is focus on it,28L/min
  • Air gun function: Has Automatic / manual function
  • Soldering iron part: Has smoke absorber function /iron sleep function
  • Air gun and Iron: has Fahrenheit/Celsius Conversion /Temperature correction function
  • Inner box size: 33*27*20.2cm
  • Outer carton box size: 56*34.5*42cm
  • Q'TY: 4pcs/ctn
  • air type: hot air /cool

Packaging & Delivery

Packaging Details export carton box,4pcs per outer carton
Delivery Time When got payment within 7 working days.



3in1 function YIHUA 992DA + upgrade version bga rework station


Product Description
Soldering Station with vacuum high precision LCD show the gun and iron temperature

Patented products, counterfeiting not allowed
Patent No. 2012303190461

Features

1. A large-screen LCD display, function indicates at a glance and nice.
2. It adopts more powerful, more stable performance of the Samsung CPU.
3. Only four buttons, operate simply and clearly.
4. Dynamic wind speed display.
5. It adopts PID precision temperature control algorithm, the temperature fluctuation range of ≤ ± 1 °C.
6. -50 °C to +50 °C temperature compensation function
7. 0-99 minutes sleep time setting function
8. Fahrenheit / Celsius temperature conversion functions.
9. Manual / automatic mode switching function
10. Soldering iron has suction smoke function, we'd never have to worry about the smoke generated by the soldering iron.
12. High temperature automatic protection and alarm functions
13. The air gun has automatic detection, protection, alarm function, and more comprehensive protection for product safety and reliability.
14, The air gun steel tube use stainless steel tube, the air gun handle lines and soldering iron handle lines are silicone wire, high temperature, you can use for a long time.
15. All functions data setting is automatically saved, without duplication.
16. The new memory automatically identify and restore to factory data.
17.  3 in 1 repairing station the combines Hot Air Rework Gun with a Soldering Iron and a Smoke Absorber
18. Additional function
a).Add to three storage sections CH1/CH2/CH3, each storage segment can store
all the features of the current machine (eg:airflow, temperature,air gun manual/
automatic mode, iron sleep time, temperature correction ...... which is currently on
 display all function values can be stored), you can quickly switch between each
storage segment.
b).Airflow adjustment knob add to cool/hot air function ,through the knob at entry /
 press out the implementation.Cool air is not heated wind, can be used to cool
components (such as circuit boards, components, etc.) temperatures.

Technical Data

Power consumption 720W
Soldering Iron Temperature range 100-480°C
Gun Temperature range 100-480°C
Gun heater material Nickel-alloys
Gun heater resistance 90Ω
Soldering Iron Type Blue Handle
Soldering Iron Heater material imported high-power heater
Gun type Diaphragm pump
Air flow 28L/min
QTY 4PCS/Outer box carton
Goods net weight. 5.13KG/PCS
OUTER  G.W. 21.65KG/CTN
Outer box size  56*34.5*42cm






Packaging & Shipping



What's in the box
* main unit + gun + power cord
* guide
* soldering iron handle with smoke absorber
* soldering iron holder +gun frame+ clean sponge
* 5 nozzles+ 5pcs smoke absorber sponge
*1 pcs IC pick-up




 Remark: the goods standard package inside not include solder wire,the pictures shows ,just in order to exhibit the soldering iron holder can layout solder wire,please note and understand,thanks.

These are 220V units you may need a transformer to use the
machine in your country. we also do accept special orders for 110V  / 230V/ 240V units.


Company Information Display



Guangzhou YIHUA Electronic Equipment CO., Ltd was founded in the 1980s, which transferred from

a large scale army enterprise called 083 base. It has become the biggest and most powerful

manufacturer for making professional rework station and soldering station and DC power supply and

our sales all over the world.

Certification of our products



We have passed the ISO9001-2008 international quality management system and our products have

passed the European CE certification, the United States,ETL certification, SAA certification, SGS

certification, the depth of export certification and Korea KC certification and so on.

Chinese Soldering Industry Standard Maker



2016,our company was invited to attend Standard Committee for Household Electrical Appliances--Chinese Soldering Industry Standard Set.

Complete Quality Test System



All of our products are passed testing by professional person before shipping, let you don't need to worry about the quality.

Our warranty

*Credit Safeguard

GuangZhou YiHua Electronic Equipments Co,. Ltd  was signed a contract with Alibaba and  paid a large deposit, make buyers fee l comfortable buying

*Factory advantage

Factory D&R / production/ sales/ and sales service together.

Manufactory  sell directly,the goods are in plenty supply,delivery date fast,good compete price You could arrange to ship the goods by your self , or  ask we help you arrange to ship. If  we help you arrange to ship. Before quote the shipping freight, we need to know which model and quantity you are asking. We will according your detail address, order model and quantity to advise  you ship by sea  or, by air ,or by Express. As usual, we are using HongKong DHL to ship the small order..

*Delivery date

Over 100~over500pcs are 20days  will ship out. Over 1000pcs are 30days .

If the material not enough or we have some customer  queue up our products before you,

we will discuss with you the shipping date. If you want the delivery date faster than that day, please inquiry us, we will try to do it as your request.

*Warranty policy

One Years warranty

As usual, the shipping fee are high. if return China to repair are not worth the money. So we could support technology and give you the spare parts along with the product .

Note: warranty does not cover wearing parts:, for example :iron heater, gun heater ,iron tips.

*Products  discount

as usual we quote three price for each model :sample price, over 60pcs price, over 500pcs price.

Those price are calculate our produce cost, as you know big order are less margin to sell. we hope take win-win business with both.

*Warm-heart  note

1.If products upgrade or quality improve to change the technique parameter, the factory will not further notice.

2.If the customer haven't special request, the product in accordance with factory's setting quality standards to produce.
